Specifications:





Series
365
Cone Part Number
368
Cup Part Number
362
Design Units
Imperial
Bearing Weight
0.5 Kg
1.1 lb
Cage Type
Stamped Steel


2. Dimensions:



d - Bore
50.8 mm
2 in
D - Cup Outer Diameter
90.000 mm
3.5433 in
B - Cone Width
22.225 mm
0.8750 in
C - Cup Width
15.875 mm
0.6250 in
T - Bearing Width
20.000 mm
0.7874 in


3. Abutment and Fillet Dimensions:
R - Cone Backface "To Clear" Radius1
1.520 mm
0.06 in
r - Cup Backface "To Clear" Radius2
2.03 mm
0.08 in
da - Cone Frontface Backing Diameter
55.88 mm
2.2 in
db - Cone Backface Backing Diameter
57.91 mm
2.28 in
Da - Cup Frontface Backing Diameter
84.10 mm
3.34 in
Db - Cup Backface Backing Diameter
81.03 mm
3.19 in
Ab - Cage-Cone Frontface Clearance
1.8 mm
0.07 in
Aa - Cage-Cone Backface Clearance
0 mm
0 in
a - Effective Center Location3
-4.3 mm
-0.17 in






4. Basic Load Ratings:



C90 - Dynamic Radial Rating (90 million revolutions)4
5930 lbf
26400 N
C1 - Dynamic Radial Rating (1 million revolutions)5
22900 lbf
102000 N
C0 - Static Radial Rating
21500 lbf
95800 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)6
3250 lbf
14400 N






---
