Specifications for this item
Bearing Number 23128E1AK M
Bearing Type Ball Bearing
Body Outside Diameter 225.00 millimeters
Bore Diameter 140 millimeters
Brand Name FAG Bearings
Compatible Lubricant Type Grease
Dynamic Load Capacity 765

Flange Thickness 68.00 millimeters

Inside Diameter 140 millimeters
Item Diameter 225 millimeters
Item Thickness 68.00 millimeters
Item Weight 21.3 pounds
Manufacturer Series Number E1 Series
Material Brass/Bronze Cage
Maximum Rotational Speed 2800 rpm
Measurement System Metric
Model Number 23128E1AKM
Number of Items 1
Part Number 23128-E1A-K-M
Specification Met Din 620-4 , Din 623-1 , Iso 281 , Iso 683-17 , Din Iso 281
Static Load Capacity 1020

Width 68 millimeters

FAG 23128E1AK-M Spherical Roller Bearing, Tapered Bore, Brass Cage, Normal Clearance, Metric, 140mm ID, 225mm OD, 68mm Width, 2800rpm Maximum Rotational Speed, 1020kN Static Load Capacity, 765kN Dynamic Load Capacity

---
